Melia LED ME2 - G431-LED

A high-performance wall-mount luminaire available in brass or powder-coated housing
Configure this product Features

Product Overview

Designed and constructed for performance, the Wall Mount Melia ME2 provides diffuse illumination in either a brass or powder-coated aluminum housing. This luminaire features Lumascape's d5 driver technology for advanced dimming and control options.

Features

Lumen Output 84 lm LED Power 3 W Power Consumption 3.6 W Input Voltage 24 Vdc Control Protocol PWM (0-10V, DMX) IP Rating IP65 Compliance CE RCM Color Options Warm White Cool White Blue (470 nm) Data Sheet

Downloads

Data Sheet Install Guide
G431-LED - IES Files.zip ZIP (19.05 KB)

Technology

Product Configurator

G431-LED _ _ _ _ _
Login to view pricing
Reset to Default Clear Selected Add

Customise Melia LED ME2 below

Light Engine

Required

3 W (3)

Light Source

Required

Static White (D7)

Static White (D7)

2,700 K (80 CRI, 3 SDCM)

Static White (H6)

Static White (H6)

3,000 K (80 CRI, 3 SDCM)

Static White (W4)

Static White (W4)

4,000 K (80 CRI, 3 SDCM)

Single Color (B4)

Single Color (B4)

Blue (470 nm)

Beam Angles

Published angles may vary slightly to photometric data. Please refer to IES files where relevant.

Required

Narrow (NR)

Narrow (NR)

14°

Narrow Medium (NM)

Narrow Medium (NM)

25°

Medium (ME)

Medium (ME)

30°

Wide (WD)

Wide (WD)

40º

Input Voltage

GardenQ

Required

24V DC - Dimmable (D)

24V DC - Dimmable (D)

PWM Dimmable Driver, 24V DC

Finish

Custom powder coat colours are available. Please consult factory.

Required

Polished Brass (PB)

Polished Brass (PB)

Polished Brass finish

Black (BL)

Black (BL)

RAL9004 from RAL Classic collection (formerly CB)

More info
Anodic Silver (SL)

Anodic Silver (SL)

RAL9006 from RAL Classic collection (formerly CS)

More info
Custom RAL (CC)

Custom RAL (CC)

A one-off custom color setup fee applies. Click on 'More Info' button to add to your enquiry. Contact Lumascape for volume discount on set-up fee.

More info

Accessories

Accessories

Copper Hood (LS603-CU)

Polished copper hood for G431-LED

Hood (G603)

Order to Match Luminaire Powder Coat Colour
