Direct View
Faisca F3
Product Overview
The Faisca F6 is an intelligent, ultra high-output marker light with a simple yet elegant design. that allows for easy and rapid installation. The plug and play electrical connections enhance the quick and easy installation process by preventing incorrect connections.
Leader cables of up to 164 ft (50 m) give greater flexibility during installation as power supplies and control equipment can be housed well away from the luminaires.
High-quality LEDs achieve high-intensity beautiful, rich and vibrant colors. From highlighting architectural elements to super-smooth crossfades and color flows.
Features
Lumen Output 2,440 lm
Power Consumption 18 W
Typical Lifetime (TM21 Reported) > 72,000 hours @ 50°C Ambient (B10, L90, TM21 Reported)
Typical Lifetime (TM21 Projected) 72,318 hours @ 50°C Ambient (B10, L90, TM21 Projected)
Input Voltage 30-48 Vdc
Control Interface PowerSync™
Control Protocol DMX/RDM, Artnet, PWM, 0-10 V (sink or source)
IP Rating IP66 / IP67 (Passes IP68 Test)
IK Rating IK10
Compliance
Color Options
Data Sheet
Color Options
Data Sheet
Specifications
Videos
Product Highlights | Faisca F6
Meet the Faisca F6, with a surface brightness of 100,000 cd/m² in RGBW, imagination is the only limit!
Accessories
| Control | |
| LS6550 | PowerSync Data Injector, Low Voltage, Generation 2 (Required for PS installations only) |
| LSLED40W-48V | DC Power Supply, 48 V, 40 W |
| LSLED80W-48V | DC Power Supply, 48 V, 80W |
| LSLED120W-48V | DC Power Supply, 48 V, 120 W |
| LSLED240W-48V | DC Power Supply, 48 V, 240 W |
| LSLED320W-48V | DC Power Supply, 48 V, 320 W |
| LSLED480W-48V | DC Power Supply, 48 V, 480 W |
| LSLED600W-48V | DC Power Supply, 48 V, 600 W |
| Shielding & Glare Control 63 or 67 Only) | |
| LS6426-PS | Leader Cable, Low Voltage 30-48 Vdc, 3-Core, PowerSync |
| LS6427-PS | Jumper Cable, Low Voltage 30-48 Vdc, 3-Core, PowerSync |
| LS6426-ND | Leader Cable, Low Voltage 30-48 Vdc, 3-Core, PowerSync |
| LS6427-ND | Jumper Cable, Low Voltage 30-48 Vdc, 3-Core, PowerSync |
| Shielding & Glare Control | |
| LS6270 | Snoot |
| LS6271 | Visor |
| Mounting & Installation | |
| LS6301 | Surface Mounting Kit |
| LS6306 | Tenon Adaptor |
| LS6307 | Tenon Adaptor |
| LS6302 | 3" Pole Clamp |
| LS6303 | 4" Pole Clamp |
| LS6304 | 4.5" Pole Clamp |
| LS6305 | 5" Pole Clamp |
| LS6258 | Wall / Pole Mount Arm |
| LS6327 | UL Junction Box |
| LS6325 | Ground Mount Post |
Downloads
Related Products
Technology
Product Configurator
Installation Type
Select the Type of Installation
